Name: AIYIMA P600 6.5 Inch Passive Speaker Wood Carbon Fiber Woofer Silk Tweeter Bookshelf Speaker for Hifi Amplifier Home Theater - eCollects.co.uk
SKU: 1005009973809133
Price: 402.00 GBP
Availability: InStock

P600 Passive Speaker Design Concept + Q&A

The P600 was born from the overall design philosophy of the AIYIMA D20, T20, and A20 HiFi system.

Our goal was to create a loudspeaker that is balanced, enjoyable to listen to, easy to drive, and highly matched.

Together with the system, it forms a coherent HiFi ecosystem that delivers a purer sonic experience for audiophiles.

Q: Why is the front panel designed with a -6° tilt?

This is the result of acoustic optimization, with two main purposes:

Time & phase alignment – Ensures tweeter and woofer sound waves reach the listener’s ears simultaneously.

Soundstage focus – The tilt projects sound energy more precisely into the optimal listening zone.

Q: What difference does this tilt make in listening experience?

Users can clearly perceive:

Improved imaging: Vocals and instruments are positioned more accurately.

Wider soundstage: Horizontal width increases by about 15% on average.

Greater tolerance: Even when deviating ±30° from the sweet spot, sound quality remains excellent.

Q: How does the horn tweeter design affect acoustics?

The P600 uses a signature 110°×110° exponential horn, made with one-piece injection molding.

Its curved transitions are acoustically optimized, controlling high-frequency dispersion to 90° horizontally and 45° vertically.

The front metal dust cover is laser-perforated, with hole density precisely calculated.

It protects the neodymium diaphragm while keeping attenuation above 20kHz within 0.5dB.

This ensures complete preservation of high-frequency details.

Q: What benefits does the solid metal phase plug bring to sound quality?

The phase plug is CNC-machined from solid aluminum alloy, with high rigidity to suppress breakup vibrations.

Its spiral surface disperses standing waves, making mid-bass transitions smoother and more natural. Aluminum’s excellent thermal conductivity also enables rapid heat dissipation.

This keeps the voice coil stable and reliable even under high-power operation.

Additional information

Weight	10 kg
Dimensions	5 cm
Brand Name	Aiyima
Inbox adaptor	No
Cabinet Material	Wood
Audio Crossover	Three-Way
Waterproof	Yes
Communication	Induction
Speaker Type	Bookshelf
Channels	2 (2.0)
Support APP	No
Battery	No
Category	Speakers
Use	others
Origin	Mainland China
Sound Mode	Stereo Sound Mode
Voice Control	No
Power Source	None
Number of Loudspeaker Enclosure	2
Input Power(W)	100-199 W
High-concerned chemical	None
Input/Output	Coaxial
Intelligent Personal Assistant	None
Certification	RoHS
Material	Wood
1	Exclusive 6° Elevated Design, Perfect for Desktop Listening
2	Carbon Fiber Woofer with Deep 30Hz Bass Extension
3	Silk Dome Horn Tweeter for Detailed & Smooth Highs
4	Solid Build Quality with Premium Components
5	Exceptional Value, Redefining Hi-Fi Performance
